Replace Type Code with State/Strategy

You have a type code that affects the behavior of a class, but you cannot use subclassing.

Replace the type code with a state object.

graphics/08fig11.gif

Motivation

This is similar to Replace Type Code with Subclasses, but can be used if the type code changes during the life of the object or if another reason prevents subclassing. It uses either the State or Strategy pattern.

State and strategy are very similar, so the refactoring is the same whichever you use, and it doesn't really matter. Choose the pattern that better fits the specific circumstances. If you are trying to simplify a single algorithm with Replace Conditional with Polymorphism, strategy is the better term. If you are going to move state-specific data and you think of the object as changing state, use the state pattern.

Mechanics

  • Self-encapsulate the type code.
  • Create a new class, and name it after the purpose of the type code. This is the state object.
  • Add subclasses of the state object, one for each type code.
    It is easier to add the subclasses all at once, rather than one at a time.
  • Create an abstract query in the state object to return the type code. Create overriding queries of each state object subclass to return the correct type code.
  • Compile.
  • Create a field in the old class for the new state object.
  • Adjust the type code query on the original class to delegate to the state object.
  • Adjust the type code setting methods on the original class to assign an instance of the appropriate state object subclass.
  • Compile and test.

Example

I again use the tiresome and brainless example of employee payment:

  class Employee {

    private int _type;
    static final int ENGINEER = 0;
    static final int SALESMAN = 1;
    static final int MANAGER = 2;

    Employee (int type) {
        _type = type;
    }

Here's an example of the kind of conditional behavior that would use these codes:

    int payAmount() {
        switch (_type) {
            case ENGINEER:
               return _monthlySalary;
            case SALESMAN:
               return _monthlySalary + _commission;
            case MANAGER:
               return _monthlySalary + _bonus;
            default:
               throw new RuntimeException("Incorrect Employee");
        }
    }

I assume this is an exciting and go-ahead company that allows promotion of managers to engineers. Thus the type code is mutable, and I can't use subclassing. My first step, as ever, is to self-encapsulate the type code:

    Employee (int type) {
        setType (type);
    }

    int getType() {
        return _type;
    }

    void setType(int arg) {
        _type = arg;
    }

    int payAmount() {
        switch (getType()) {
            case ENGINEER:
               return _monthlySalary;
            case SALESMAN:
               return _monthlySalary + _commission;
            case MANAGER:
               return _monthlySalary + _bonus;
            default:
               throw new RuntimeException("Incorrect Employee");
        }
    }

Now I declare the state class. I declare this as an abstract class and provide an abstract method for returning the type code:

  abstract class EmployeeType {
    abstract int getTypeCode();
  }

I now create the subclasses:

  class Engineer extends EmployeeType {
    int getTypeCode () {
        return Employee.ENGINEER;
    }
  }

class Manager extends EmployeeType {
    int getTypeCode () {
        return Employee.MANAGER;
    }
  }

class Salesman extends EmployeeType {
    int getTypeCode () {
        return Employee.SALESMAN;
    }
  }

I compile so far, and it is all so trivial that even for me it compiles easily. Now I actually hook the subclasses into the employee by modifying the accessors for the type code:

  class Employee...
    private EmployeeType _type;

    int getType() {
        return _type.getTypeCode();
    }

    void setType(int arg) {
        switch (arg) {
            case ENGINEER:
               _type = new Engineer();
               break;
            case SALESMAN:
               _type = new Salesman();
               break;
            case MANAGER:
               _type = new Manager();
               break;
            default:
               throw new IllegalArgumentException("Incorrect Employee Code");
        }
    }

This means I now have a switch statement here. Once I'm finished refactoring, it will be the only one anywhere in the code, and it will be executed only when the type is changed. I can also use Replace Constructor with Factory Method to create factory methods for different cases. I can eliminate all the other case statements with a swift thrust of Replace Conditional with Polymorphism.

I like to finish Replace Type Code with State/Strategy by moving all knowledge of the type codes and subclasses over to the new class. First I copy the type code definitions into the employee type, create a factory method for employee types, and adjust the setting method on employee:

  class Employee...
    void setType(int arg) {
        _type = EmployeeType.newType(arg);
    }

class EmployeeType...
    static EmployeeType newType(int code) {
        switch (code) {
            case ENGINEER:
               return new Engineer();
            case SALESMAN:
               return new Salesman();
            case MANAGER:
               return new Manager();
            default:
               throw new IllegalArgumentException("Incorrect Employee Code");
        }
    }
    static final int ENGINEER = 0;
    static final int SALESMAN = 1;
    static final int MANAGER = 2;

Then I remove the type code definitions from the employee and replace them with references to the employee type:

  class Employee...
    int payAmount() {
        switch (getType()) {
            case EmployeeType.ENGINEER:
               return _monthlySalary;
            case EmployeeType.SALESMAN:
               return _monthlySalary + _commission;
            case EmployeeType.MANAGER:
               return _monthlySalary + _bonus;
            default:
               throw new RuntimeException("Incorrect Employee");
        }
    }

I'm now ready to use Replace Conditional with Polymorphism on payAmount.
