Replace Subclass with Fields

You have subclasses that vary only in methods that return constant data.

Change the methods to superclass fields and eliminate the subclasses.

graphics/08fig12.gif

Motivation

You create subclasses to add features or allow behavior to vary. One form of variant behavior is the constant method [Beck]. A constant method is one that returns a hard-coded value. This can be very useful on subclasses that return different values for an accessor. You define the accessor in the superclass and implement it with different values on the subclass.

Although constant methods are useful, a subclass that consists only of constant methods is not doing enough to be worth existing. You can remove such subclasses completely by putting fields in the superclass. By doing that you remove the extra complexity of the subclasses.

Mechanics

  • Use Replace Constructor with Factory Method on the subclasses.
  • If any code refers to the subclasses, replace the reference with one to the superclass.
  • Declare final fields for each constant method on the superclass.
  • Declare a protected superclass constructor to initialize the fields.
  • Add or modify subclass constructors to call the new superclass constructor.
  • Compile and test.
  • Implement each constant method in the superclass to return the field and remove the method from the subclasses.
  • Compile and test after each removal.
  • When all the subclass methods have been removed, use Inline Method to inline the constructor into the factory method of the superclass.
  • Compile and test.
  • Remove the subclass.
  • Compile and test.
  • Repeat inlining the constructor and elminating each subclass until they are all gone.

Example

I begin with a person and sex-oriented subclasses:

  abstract class Person {

    abstract boolean isMale();
    abstract char getCode();
  ...

  class Male extends Person {
    boolean isMale() {
        return true;
    }
    char getCode() {
        return 'M';
    }
  }

  class Female extends Person {
    boolean isMale() {
        return false;
    }
    char getCode() {
        return 'F';
    }
  }

Here the only difference between the subclasses is that they have implementations of abstract methods that return a hard-coded constant method [Beck]. I remove these lazy subclasses.

First I need to use Replace Constructor with Factory Method. In this case I want a factory method for each subclass:

  class Person...
    static Person createMale(){
        return new Male();
    }
    static Person createFemale() {
        return new Female();
    }

I then replace calls of the form

  Person kent = new Male();

with

  Person kent = Person.createMale();

Once I've replaced all of these calls I shouldn't have any references to the subclasses. I can check this with a text search and check that at least nothing accesses them outside the package by making the classes private.

Now I declare fields for each constant method on the superclass:

  class Person...
    private final boolean _isMale;
    private final char _code;

I add a protected constructor on the superclass:

  class Person...
    protected Person (boolean isMale, char code) {
        _isMale = isMale;
        _code = code;
    }

I add constructors that call this new constructor:

  class Male...
    Male() {
        super (true, 'M');
    }
  class Female...
    Female() {
        super (false, 'F');
    }

With that done I can compile and test. The fields are created and initialized, but so far they aren't being used. I can now start bringing the fields into play by putting accessors on the superclass and eliminating the subclass methods:

  class Person...
    boolean isMale() {
        return _isMale;
    }
  class Male...
    boolean isMale() {
        return true;
    }

I can do this one field and one subclass at a time or all in one go if I'm feeling lucky.

After all the subclasses are empty, so I remove the abstract marker from the person class and use Inline Method to inline the subclass constructor into the superclass:

  class Person
    static Person createMale(){
        return new Person(true, 'M');
    }

After compiling and testing I delete the male class and repeat the process for the female class.
