Hide Delegate

A client is calling a delegate class of an object.

Create methods on the server to hide the delegate.

graphics/07fig05.gif

Motivation

One of the keys, if not the key, to objects is encapsulation. Encapsulation means that objects need to know less about other parts of the system. Then when things change, fewer objects need to be told about the change—which makes the change easier to make.

Anyone involved in objects knows that you should hide your fields, despite the fact that Java allows fields to be public. As you become more sophisticated, you realize there is more you can encapsulate.

If a client calls a method defined on one of the fields of the server object, the client needs to know about this delegate object. If the delegate changes, the client also may have to change. You can remove this dependency by placing a simple delegating method on the server, which hides the delegate (Figure 7.1). Changes become limited to the server and don't propagate to the client.

Figure 7.1. Simple delegation
graphics/07fig06.gif

You may find it is worthwhile to use Extract Class for some clients of the server or all clients. If you hide from all clients, you can remove all mention of the delegate from the interface of the server.

Mechanics

  • For each method on the delegate, create a simple delegating method on the server.
  • Adjust the client to call the server.
    If the client is not in the same package as the server, consider changing the delegate method's access to package visibility.
  • Compile and test after adjusting each method.
  • If no client needs to access the delegate anymore, remove the server's accessor for the delegate.
  • Compile and test.

Example

I start with a person and a department:

  class Person {
    Department _department;

    public Department getDepartment() {
        return _department;
    }
    public void setDepartment(Department arg) {
        _department = arg;
    }
  }

  class Department {
    private String _chargeCode;
    private Person _manager;

    public Department (Person manager) {
        _manager = manager;
    }

    public Person getManager() {
        return _manager;
    }
  ...

If a client wants to know a person's manager, it needs to get the department first:

  manager = john.getDepartment().getManager();

This reveals to the client how the department class works and that the department is responsible to tracking the manager. I can reduce this coupling by hiding the department class from the client. I do this by creating a simple delegating method on person:

    public Person getManager() {
        return _department.getManager();
    }

I now need to change all clients of person to use this new method:

  manager = john.getManager();

Once I've made the change for all methods of department and for all the clients of person, I can remove the getDepartment accessor on person.
