Replace Inheritance with Delegation

A subclass uses only part of a superclasses interface or does not want to inherit data.

Create a field for the superclass, adjust methods to delegate to the superclass, and remove the subclassing.

graphics/11fig14.gif

Motivation

Inheritance is a wonderful thing, but sometimes it isn't what you want. Often you start inheriting from a class but then find that many of the superclass operations aren't really true of the subclass. In this case you have an interface that's not a true reflection of what the class does. Or you may find that you are inheriting a whole load of data that is not appropriate for the subclass. Or you may find that there are protected superclass methods that don't make much sense with the subclass.

You can live with the situation and use convention to say that although it is a subclass, it's using only part of the superclass function. But that results in code that says one thing when your intention is something else—a confusion you should remove.

By using delegation instead, you make it clear that you are making only partial use of the delegated class. You control which aspects of the interface to take and which to ignore. The cost is extra delegating methods that are boring to write but are too simple to go wrong.

Mechanics

  • Create a field in the subclass that refers to an instance of the superclass. Initialize it to this.

  • Change each method defined in the subclass to use the delegate field. Compile and test after changing each method.

    You won't be able to replace any methods that invoke a method on super that is defined on the subclass, or they may get into an infinite recurse. These methods can be replaced only after you have broken the inheritance.

  • Remove the subclass declaration and replace the delegate assignment with an assignment to a new object.
  • For each superclass method used by a client, add a simple delegating method.
  • Compile and test.

Example

One of the classic examples of inappropriate inheritance is making a stack a subclass of vector. Java 1.1 does this in its utilities (naughty boys!), but in this case I use a simplified form of stack:

 class MyStack extends Vector {

    public void push(Object element) {
        insertElementAt(element,0);
    }

    public Object pop() {
        Object result = firstElement();
        removeElementAt(0);
        return result;
    }
 }

Looking at the users of the class, I realize that clients do only four things with stack: push, pop, size, and isEmpty. The latter two are inherited from Vector.

I begin the delegation by creating a field for the delegated vector. I link this field to this so that I can mix delegation and inheritance while I carry out the refactoring:

  private Vector _vector = this;

Now I start replacing methods to get them to use the delegation. I begin with push:

      public void push(Object element) {
        _vector.insertElementAt(element,0);
    }

I can compile and test here, and everything will still work. Now pop:

      public Object pop() {
        Object result = _vector.firstElement();
        _vector.removeElementAt(0);
        return result;
    }

Once I've completed these subclass methods, I need to break the link to the superclass:

 class MyStack extends Vector

   private Vector _vector = new Vector();

I then add simple delegating methods for superclass methods used by clients:

   public int size() {
       return _vector.size();
   }
   public boolean isEmpty() {
       return _vector.isEmpty();
   }

Now I can compile and test. If I forgot to add a delegating method, the compilation will tell me.
