Replace Type Code with Class

A class has a numeric type code that does not affect its behavior.

Replace the number with a new class.

graphics/08fig09.gif

Motivation

Numeric type codes, or enumerations, are a common feature of C-based languages. With symbolic names they can be quite readable. The problem is that the symbolic name is only an alias; the compiler still sees the underlying number. The compiler type checks using the number not the symbolic name. Any method that takes the type code as an argument expects a number, and there is nothing to force a symbolic name to be used. This can reduce readability and be a source of bugs.

If you replace the number with a class, the compiler can type check on the class. By providing factory methods for the class, you can statically check that only valid instances are created and that those instances are passed on to the correct objects.

Before you do Replace Type Code with Class, however, you need to consider the other type code replacements. Replace the type code with a class only if the type code is pure data, that is, it does not cause different behavior inside a switch statement. For a start Java can only switch on an integer, not an arbitrary class, so the replacement will fail. More important than that, any switch has to be removed with Replace Conditional with Polymorphism. In order for that refactoring, the type code first has to be handled with Replace Type Code with Subclasses or Replace Type Code with State/Strategy.

Even if a type code does not cause different behavior depending on its value, there might be behavior that is better placed in the type code class, so be alert to the value of a Move Method or two.

Mechanics

  • Create a new class for the type code.
    The class needs a code field that matches the type code and a getting method for this value. It should have static variables for the allowable instances of the class and a static method that returns the appropriate instance from an argument based on the original code.
  • Modify the implementation of the source class to use the new class.
    Maintain the old code-based interface, but change the static fields to use new class to generate the codes. Alter the other code-based methods to get the code numbers from the new class.
  • Compile and test.
    At this point the new class can do run-time checking of the codes.
  • For each method on the source class that uses the code, create a new method that uses the new class instead.

    Methods that use the code as an argument need new methods that use an instance of the new class as an argument. Methods that return a code need a new method that returns the code. It is often wise to use Rename Method on an old accessor before creating a new one to make the program clearer when it is using an old code.

  • One by one, change the clients of the source class so that they use the new interface.
  • Compile and test after each client is updated.
    You may need to alter several methods before you have enough consistency to compile and test.
  • Remove the old interface that uses the codes, and remove the static declarations of the codes.
  • Compile and test.

Example

A person has a blood group modeled with a type code:

  class Person {
    public static final int O = 0;
    public static final int A = 1;
    public static final int B = 2;
    public static final int AB = 3;

    private int _bloodGroup;

    public Person (int bloodGroup) {
        _bloodGroup = bloodGroup;
    }

    public void setBloodGroup(int arg) {
        _bloodGroup = arg;
    }

    public int getBloodGroup() {
        return _bloodGroup;
    }
  }

I start by creating a new blood group class with instances that contain the type code number:

  class BloodGroup {
    public static final BloodGroup O = new BloodGroup(0);
    public static final BloodGroup A = new BloodGroup(1);
    public static final BloodGroup B = new BloodGroup(2);
    public static final BloodGroup AB = new BloodGroup(3);
    private static final BloodGroup[] _values = {O, A, B, AB};

    private final int _code;

    private BloodGroup (int code ) {
        _code = code;
    }

    public int getCode() {
        return _code;
    }

    public static BloodGroup code(int arg) {
        return _values[arg];
    }
  }

I then replace the code in Person with code that uses the new class:

  class Person {
    public static final int O = BloodGroup.O.getCode();
    public static final int A = BloodGroup.A.getCode();
    public static final int B = BloodGroup.B.getCode();
    public static final int AB = BloodGroup.AB.getCode();

    private BloodGroup _bloodGroup;

    public Person (int bloodGroup) {
        _bloodGroup = BloodGroup.code(bloodGroup);
    }

    public int getBloodGroup() {
        return _bloodGroup.getCode();
    }

    public void setBloodGroup(int arg) {
        _bloodGroup = BloodGroup.code (arg);
    }
  }

At this point I have run-time checking within the blood group class. To really gain from the change I have to alter the users of the person class to use blood group instead of integers.

To begin I use Rename Method on the accessor for the person's blood group to clarify the new state of affairs:

  class Person...
    public int getBloodGroupCode() {
        return _bloodGroup.getCode();
    }

I then add a new getting method that uses the new class:

    public BloodGroup getBloodGroup() {
        return _bloodGroup;
    }

I also create a new constructor and setting method that uses the class:

  public Person (BloodGroup bloodGroup ) {
    _bloodGroup = bloodGroup;
  }

  public void setBloodGroup(BloodGroup arg) {
    _bloodGroup = arg;
  }

Now I go to work on the clients of Person. The art is to work on one client at a time so that you can take small steps. Each client may need various changes, and that makes it more tricky. Any reference to the static variables needs to be changed. So

  Person thePerson = new Person(Person.A)

becomes

    Person thePerson = new Person(BloodGroup.A);

References to the getting method need to use the new one, so

  thePerson.getBloodGroupCode()

becomes

  thePerson.getBloodGroup().getCode()

The same is true for setting methods, so

  thePerson.setBloodGroup(Person.AB)

becomes

  thePerson.setBloodGroup(BloodGroup.AB)

Once this is done for all clients of Person, I can remove the getting method, constructor, static definitions, and setting methods that use the integer:

  class Person ...
    public static final int O = BloodGroup.O.getCode();
    public static final int A = BloodGroup.A.getCode();
    public static final int B = BloodGroup.B.getCode();
    public static final int AB = BloodGroup.AB.getCode();
    public Person (int bloodGroup) {
        _bloodGroup = BloodGroup.code(bloodGroup);
    }
    public int getBloodGroup() {
        return _bloodGroup.getCode();
    }
    public void setBloodGroup(int arg) {
        _bloodGroup = BloodGroup.code (arg);
    }

I can also privatize the methods on blood group that use the code:

  class BloodGroup...
    private int getCode() {
        return _code;
    }

    private static BloodGroup code(int arg) {
        return _values[arg];
    }
