Change Bidirectional Association to Unidirectional

You have a two-way association but one class no longer needs features from the other.

Drop the unneeded end of the association.

graphics/08fig07.gif

Motivation

Bidirectional associations are useful, but they carry a price. The price is the added complexity of maintaining the two-way links and ensuring that objects are properly created and removed. Bidirectional associations are not natural for many programmers, so they often are a source of errors.

Lots of two-way links also make it easy for mistakes to lead to zombies: objects that should be dead but still hang around because of a reference that was not cleared.

Bidirectional associations force an interdependency between the two classes. Any change to one class may cause a change to another. If the classes are in separate packages, you get an interdependency between the packages. Many interdependencies lead to a highly coupled system, in which any little change leads to lots of unpredictable ramifications.

You should use bidirectional associations when you need to but not when you don't. As soon as you see a bidirectional association is no longer pulling its weight, drop the unnecessary end.

Mechanics

  • Examine all the readers of the field that holds the pointer that you wish to remove to see whether the removal is feasible.
    Look at direct readers and further methods that call the methods.

    Consider whether it is possible to determine the other object without using the pointer. If so you will be able to use Substitute Algorithm on the getter to allow clients to use the getting method even if there is no pointer.

    Consider adding the object as an argument to all methods that use the field.

  • If clients need to use the getter, use Self Encapsulate Field, carry out Substitute Algorithm on the getter, compile, and test.
  • If clients don't need the getter, change each user of the field so that it gets the object in the field another way. Compile and test after each change.
  • When no reader is left in the field, remove all updates to the field, and remove the field.

    If there are many places that assign the field, use Self Encapsulate Field so that they all use a single setter. Compile and test. Change the setter to have an empty body. Compile and test. If that works, remove the field, the setter, and all calls to the setter.

  • Compile and test.

Example

I start from where I ended up from the example in Change Unidirectional Association to Bidirectional. I have a customer and order with a bidirectional link:

  class Order...
    Customer getCustomer() {
        return _customer;
    }
    void setCustomer (Customer arg) {
        if (_customer != null) _customer.friendOrders().remove(this);
        _customer = arg;
        if (_customer != null) _customer.friendOrders().add(this);
    }
    private Customer _customer;

  class Customer...
    void addOrder(Order arg) {
        arg.setCustomer(this);
    }
    private Set _orders = new HashSet();
    Set friendOrders() {
        /** should only be used by Order */
        return _orders;
    }

I've found that in my application I don't have orders unless I already have a customer, so I want to break the link from order to customer.

The most difficult part of this refactoring is checking that I can do it. Once I know it's safe to do, it's easy. The issue is whether code relies on the customer field's being there. To remove the field, I need to provide an alternative.

My first move is to study all the readers of the field and the methods that use those readers. Can I find another way to provide the customer object? Often this means passing in the customer as an argument for an operation. Here's a simplistic example of this:

  class Order...
        double getDiscountedPrice() {
        return getGrossPrice() * (1 - _customer.getDiscount());
    }

changes to

  class Order...
    double getDiscountedPrice(Customer customer) {
        return getGrossPrice() * (1 - customer.getDiscount());
    }

This works particularly well when the behavior is being called by the customer, because then it's easy to pass itself in as an argument. So

  class Customer...
    double getPriceFor(Order order) {
        Assert.isTrue(_orders.contains(order)); // see Introduce Assertion (267)
        return order.getDiscountedPrice();

becomes

  class Customer...
    double getPriceFor(Order order) {
        Assert.isTrue(_orders.contains(order));
        return order.getDiscountedPrice(this);
    }

Another alternative I consider is changing the getter so that it gets the customer without using the field. If it does, I can use Substitute Algorithm on the body of Order.getCustomer. I might do something like this:

    Customer getCustomer() {
        Iterator iter = Customer.getInstances().iterator();
        while (iter.hasNext()) {
            Customer each = (Customer)iter.next();
            if (each.containsOrder(this)) return each;
        }
        return null;
    }

Slow, but it works. In a database context it may not even be that slow if I use a database query. If the order class contains methods that use the customer field, I can change them to use getCustomer by using Self Encapsulate Field.

If I retain the accessor, the association is still bidirectional in interface but is unidirectional in implementation. I remove the backpointer but retain the interdependencies between the two classes.

If I substitute the getting method, I substitute that and leave the rest till later. Otherwise I change the callers one at a time to use the customer from another source. I compile and test after each change. In practice, this process usually is pretty rapid. If it were complicated, I would give up on this refactoring.

Once I've eliminated the readers of the field, I can work on the writers of the field. This is as simple as removing any assignments to the field and then removing the field. Because nobody is reading it any more, that shouldn't matter.
